A stack-based language implemented in OCaml and compiled to WebAssembly
Stackl is a stack-based programming language designed to be simple yet powerful. It is implemented in OCaml and compiled to WebAssembly, allowing it to run efficiently in web environments.
| Function | Description | Arguments | Example |
|---|---|---|---|
| dup | Duplicate the top value on the stack. | None | 3 dup |
| exch | Exchange the top two values on the stack. | None | 3 4 exch |
| puts | Print the top value on the stack. | None | 3 puts |
| load | Load a variable from the environment. | Symbol | x load |
| pi | Push the value of pi onto the stack. | None | pi |
| save | Save the current drawing state. | None | save |
| restore | Restore the last saved drawing state. | None | restore |
| translate | Translate the drawing context. | x, y | 10 20 translate |
| rotate | Rotate the drawing context. | angle | 45 rotate |
| begin_path | Begin a new path for drawing. | None | begin_path |
| move_to | Move the drawing cursor to a new position. | x, y | 100 150 move_to |
| line_to | Draw a line to a new position. | x, y | 200 250 line_to |
| stroke | Stroke the current path. | None | stroke |
| set_fill_style | Set the fill style for drawing. | r, g, b | 255 0 0 set_fill_style |
Stackl supports basic arithmetic operations such as addition, subtraction, multiplication, and division.
| Operation | Description | Example |
|---|---|---|
| Addition (+) | Adds the top two values on the stack. | 3 4 + results in 7 |
| Subtraction (-) | Subtracts the top value from the second top value on the stack. | 10 4 - results in 6 |
| Multiplication (*) | Multiplies the top two values on the stack. | 3 4 * results in 12 |
| Division (div) | Divides the second top value by the top value on the stack. | 12 4 div results in 3 |
Stackl supports conditional execution using the if statement.
Example: { 1 2 < } { 10 puts } { 20 puts } if will print 10 if the condition { 1 2 < } is true, otherwise 20.
Define and call functions using the def keyword. Loops can be
implemented using recursive functions.
Example: /square { dup * } def defines a function square that squares a number. Use it as 5 square.
Example: /loop { /i exch def { i 5 < } { i puts i 1 + loop } { } if } def. Use
it as 0 loop.
Stackl provides various operations to manipulate the stack.
Example: 3 4 exch swaps the top two values, resulting in 4 3.
The exch operation can also be used for variable definition by
swapping the top two values on the stack. This is useful for assigning values to variables.
Example: /x exch def assigns the last value pushed to the stack
to the variable
x.
